Small businesses and corporate workgroups depend on solutions that help maximize resources, boost productivity, and are easy to manage. The cost-efficient imageRUNNER 1643 Series can do all that, and more. With fast output, scanning, faxing, and high reliability, these multifunction devices help you accomplish a lot in a small space.

Canon imageRUNNER 1643if MFP mono A4 4-in-1 Laser Printer, Print, Copy, Scan, Send, Fax, 12.7cm TFT LCD WVGA Colour touch panel Control Panel, USB 2.0, WiFi, Gigabit LAN, 600×600 dpi print Resolution, 43 ppm (A4) print speed (Bw), 43 ppm (A4) Copy speed, ADF / flat Scanner, Single-pass duplexing automatic Document feeder Scanner, 600×600 scan Resolution (dpi), 650 sheets standard paper supply capacity, 150 sheets paper Output capacity


Collapse All

Workflow Efficiency
Whether you’re a small business or part of a workgroup, the imageRUNNER 1643iF model can help boost operational efficiency. Scan and email documents to clients and colleagues or conveniently scan to/print from a USB memory stick. The ID Card Copy feature easily copies cards and other small, two-sided documents onto the same page. Extend your document management capabilities when you scan using the standard PDF (OCR) format. This model enables mobile workers and offices the ability to scan to/ print from compatible mobile devices. Application Library provides users with a unique, customized device experience.

Safeguard information and help ensure security compliance with the imageRUNNER 1643iF model. Canon’s uniFLOW solution lets users securely retrieve documents from any networked device after authentication. Standard security features include the ability to send encrypted PDFs and add a digital device signature to PDF files. These models also include technology to verify that the device boot process, firmware, and applications initialize without tampering. TX Archiving automatically forwards a copy of a fax to an administrator-defined destination. And with no hard disks in these models, there are no latent images.

Efficient Performance
Designed with your bottom line in mind, the Canon imageRUNNER 1643iF helps minimize costs and maximize reliability while the robust design helps ensure dependable operation. Canon’s uniFLOW software can help control costs by managing, tracking, and charging back usage. And simple-to-replace, high-yield consumables help keep work moving while achieving a low cost per page.

Fleet Management
An ideal replacement for single-function printers or older models, the imageRUNNER 1643iF can easily integrate into your network of Canon devices to help streamline and simplify management and maintenance. Even receive alerts when supplies or service calls are needed with imageWARE Enterprise Management Console and plug-ins.

Quality and Reliability
With a first-copy-out time as fast as 6.3 seconds and output up to 45 ppm, the imageRUNNER 1643iF is a quick performer. Scan documents in black and white and color to email addresses or networked locations. The 5″ intuitive, color touchscreen display has smartphone-like usability. The standard 650-sheet capacity can be increased to 2,300 sheets to handle many jobs without interruption.

The imageRUNNER 1643iF is ENERGY STAR certified and has a low TEC (Total Energy Consumption) rating. Rated EPEAT Silver, these models follow Canon’s stringent Green Procurement policy and environmental commitments.

SKU: 1643IF Categories: , ,




Product Code CANON imageRUNNER 1643iF MFPspacer
Main Unit
Machine type Monochrome A4 Laser Multifunctional
Core functions iR 1643iF: Print, Copy, Scan, Send and Fax
iR 1643i: Print, Copy, Scan and Send
Processor Canon Custom Processor
Control Panel 12.7cm/5″ TFT LCD WVGA Colour Touch panel
Memory Standard: 1.0GB RAM
Interface Connection NETWORK Standard:
1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), NFC (iR 1643iF only), Wi-Fi Direct Connection
OTHERS Standard:
USB 2.0 (Host) x2, USB 2.0 (Device) x1
Paper Supply Capacity (A4, 80gsm) Standard: 650 sheets
Paper Cassette: 550-sheet
Multi-purpose tray: 100-sheet
Maximum: 2,300 sheets (with Paper Feeder PF-C1 (x3))
Paper Output Capacity (A4, 80gsm) 150 sheets
Supported media types Upper Cassette 1:
Thin, Plain, Thick, Colour, Recycled, Bond
Multi-purpose tray:
Thin, Plain, Thick, Colour, Recycled, Bond, Label, Envelope
Supported media sizes Upper Cassette 1:
Standard size: A4, B5, A5, A5R, A6
Custom size: Min. 105.0 x 148.0 mm up to 216.0 x 355.6 mm
Multi-purpose tray:
Standard size: A4, B5, A5, A5R, A6
Index Card, Envelopes [No. 10 (COM 10), Monarch, ISO-C5, DL]
Custom Size: Min. 76.2 x 127.0 mm up to 216.0 x 355.6 mm
Supported media weights Upper Cassette 1: 60 to 120 gsm
Multi-purpose tray: 60 to 199 gsm
Duplex: 60 to 120 gsm
Warm-up Time From Power On: 14 Seconds or Less
From Sleep Mode: 4 Seconds or Less
* Time from device power-on, until copy ready (not print reservation)
Dimensions (W x D x H) 1643i: 480 x 595 x 452 mm (with the Multi-purpose tray extended)
1643iF: 494 x 595 x 452 mm (with the Multi-purpose tray extended)
Installation Space (W x D) 1643i: 694 x 1105 mm (with Cassette open + 100 mm gap around the main body)
1643iF: 708 x 1105 mm (with Cassette open + 100 mm gap around the main body)
Weight Standard: Approx. 19 kg without toner
Print Specifications
Print Speed (BW) iR 1643iF/1643i:
43 ppm (A4)
Print Resolution 600 x 600 dpi
Print Quality with Image Refinement Technology Up to 1200 x 1200 dpi
Page description languages Standard: UFR II, PCL6, PCL5, Adobe PostScript 3TM
Direct Print Direct printing available from USB memory, LPR
Supported file types: TIFF, JPEG, PDF and XPS (only LPR)
Printing from mobile and cloud Apple Air Print, Canon PRINT Business, Mopria, Google Cloud Print, and uniFLOW Online
A range of software solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
Please contact your sales representative for further information
Fonts PCL fonts: 93 Roman
PS fonts: 136 Roman
Print Features Suspend Job Timeout, Profile Settings, Secure Print, Header/Footer, Page Layout, Two-sided Printing, Collating, Booklet Printing, Grouping, Mixed Paper Sizes/ Orientations, Front/Back Covers, Toner Reduction, Poster Printing
Operating System UFRII/PCL/PS: Windows 7/8.1/10/Server 2008/Server2008 R2/Server2012/Server2012 R2/Server2016, Mac OS X (10.9 or later)
Copy Specifications
Copy Speed iR 1643iF/1643i:
43 ppm (A4)
First-Copy-Out Time (BW) Platen: Approx. 6.3 seconds or less
ADF: Approx. 6.4 seconds or less
Copy resolution (dpi) Reading: 600 x 600
Printing: 600 x 600
Multiple Copies UP to 999 copies
Copy Density Automatic or Manual (9 Levels)
Magnification 25% – 400% (1% Increments)
Preset Reductions 25%, 50%, 70%, 81%, 86%
Preset Enlargements 115%, 122%, 141%, 200%, 400%
Basic Copy Features Preset R/E Ratios by Area, Paper Setting, Favourite Setting, Two-Sided, Density Adjustment, Original Type Selection
Special Copy Features Two-sided Original, Job Build, N on 1, Different Size Originals, Density Adjustment, Original Type Selection, Sharpness, Erase Frame, Job Done Notice, Copy ID Card, Collate
Scan Specifications
Document Feeder type Standard: Single-Pass Duplexing Automatic Document Feeder
Paper Capacity A4: 50 sheets (80 gsm)
Acceptable Originals and weights Platen: Sheet, Book, 3-Dimensional Objects (Height: up to 20mm)
Document Feeder sheet media weight :
1-sided/2-sided continuous scanning: 50 to 105 gsm
Supported media sizes Sheet media size: A4R, B5R, A5R, A6R
Custom size: 105×128 mm to 215.9×355.6 mm
Scan Speed (ipm: BW/CL, A4) Copy:
1-sided Scanning: 20
2-sided Scanning: 34
1-sided Scanning (BW): 38
1-sided Scanning (CL): 13
2-sided Scanning (BW): 70
2-sided Scanning (CL): 26
Scan Resolution (dpi) Copy: 600 x 600
Send: (Push) up to 600 x 600, (Pull) up to 600 x 600
Fax: up to 600 x 600
Pull Scan Specifications ScanGear MF For both TWAIN and WIA
Windows 7/8.1 /10/Server2008/Server2008 R2/Server2012/Server2012 R2/Server2016, Mac OS X (10.9 or later)
Scan Method Send functionality available on both models
Scan to USB Memory Key
Scan to Mobile Devices and cloud-based services: A range of solutions is available to provide scanning to mobile devices or cloud-based services depending on your requirements. Please contact your sales representative for further information.
TWAIN/WIA Pull scanning available on both models
Send Specifications
Destination E-mail/Internet FAX (SMTP), SMB, FTP
Address Book/Speed dials LDAP (50)/Local (300)/Speed dial (281)
Send resolution (dpi) Push: 196 x 204 (I-FAX)
300 x 300 (email/SMB/FTP)
Pull: Max. 9600 x 9600
Communication protocol File: FTP, SMB
E-mail/I-Fax: SMTP, POP3, I-Fax (Simple)
File Format Standard: TIFF, JPEG, PDF (Compact, Searchable, Encrypted, Digital Signature)
Universal Send Features Original Type Selection, Two-sided Original, Density Adjustment, Sharpness, File Name, Subject/Message, E-mail Priority, TX Report, Original Content Orientation
Fax Specifications
Optional / Standard iR 1643iF: Standard
Maximum Number of Connection Lines 1
Modem Speed Super G3: 33.6 kbps
G3: 14.4 kbps
Compression Method MH, MR, MMR, JBIG
Resolution (dpi) 400 x 400 (Ultrafine), 200 x 400 (Superfine), 200 x 200 (Fine/ Photo), 200 x 100 (Normal)
Sending/Recording Size A4, B5*1, A5*1, A6*1
*1 Sent as A4
FAX memory Up to 512 pages
Speed dials Max. 281
Group dials/destinations Max. 299 dials
Sequential broadcast Max. 310 addresses
Memory backup Yes
Fax Features Two-sided Original, Density (for Scanning), Sharpness, TX Report, RX Mode, Resolutions, Favourite Settings
Store Specifications
Memory Media Standard: USB Memory
Security Specifications
Authentication Embeded Universal Login Manager with uniFLOW Online/Online Express*, Department ID Authentication.
*No charge for this solution, however, activation is required
Network Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP
Document Standard: Secure Print, Encrypted PDF, Device signature
Environmental Specifications
Operating Environment Temperature: 10 to 30 ºC (50 to 86 ºF)
Humidity: 20 to 80 % RH (Relative Humidity)
Power Source AC220-240V:3.9A, 50/60Hz
Plug (Main Unit) CEE7/7
Power Consumption Maximum: Approx. 1420W or less
Standby: Approx. 13.6 W
Sleep mode: Approx. 0.9 W
Plugin Off: Approx. 0.1W or less
Typical Electricity Consumption (TEC)* : 1.4 kWh
*As per US ENERGY STAR version 2.0
Noise levels (BW/CL) Sound Power Level (LwAd)
Active: 72.9 dB or Less*1
Standby: LwAm 3.7B, Kv 0.3B*2
Sound Pressure Level (LpAm)
Bystander’s position:
Active: 1-sided:LpAm 54 dB, 2-sided:LpAm 53 dB
Standby: 24 dB
*1 RAL-UZ205(2017) compliant (Data taken from Blue Angel Standard value)
*2 Reference value: measured only one unit with ISO7779, described with ISO9296:2017
Standards Blue Angel
Toner Cartridge/s Toner T06 Black
Toner (Estimated Yield @5% Coverage) Black: 20,500 impressions (A4)
Software and Printer management
Tracking and reporting Universal Login Manager (ULM)*:
Manage your costs easily by using the embedded reporting capability to identify and control costs on a user-based level by device. uniFLOW Online Express: Combining with ULM you can gain further control and highlight expenditures per users/department and pinpoint where costs can be scaled down from a central cloud-based location.
*Installation, activation & registration required
Remote management tools iW Management Console:
Server-based software for centralised management of a fleet of devices (includes monitoring or consumables, status monitoring and alerts, distribution of address books, configuration settings, firmware, meter capture and reporting, driver and resource management)
Compatible with eMaintenance services via embedded RDS (Enables meter capture, automatic consumables management, remote diagnostics and reporting for service providers to offer efficient, fast and proactive maintenance)
Application Library
Scanning software Network ScanGear:
TWAIN-compliant scanner driver that enables computers on a network to use the pull scan functionality of the device
Paper Supply options
Feeder Options PAPER FEEDER PF-C1
Paper Capacity: 550 sheets (80 gsm)
Paper Type: Thin, Plain, Thick, Colour, Recycled, Bond
Paper Size: A4, B5, A5, A5R, A6
Custom size: 105.0 x 148.0mm to 216.0 x 355.6mm
Paper Weight: 60 to 120 gsm
Power Source: From the Main Unit
Dimensions (W x D x H): 480 x 464 x 842*mm (*attached to the main unit)
Weight: Approx. 4.0 kg
Hardware Accessories
Card Readers MICARD ATT KIT-B1
System and Controles Options
Barcode Printing BARCODE PRT KIT-E1E EU
System Accessories CONTROL I/F KIT-C1
Other Options
Accessibility Accessories TEL 6 KIT UK LONG CORD
